An amp-hour is one amp for one hour, or 10 amps for 1/10 of an hour and so forth. It is amps X hours. If you have something that pulls 20 amps, and you use it for 20 minutes, then the amp-hours used would be 20 (amps) X .333 (hours), or 6.67 AH. The accepted AH rating time period for batteries used in solar electric and backup power systems (and for nearly all deep cycle batteries) is the '20 hour rate'. This means that it is discharged down to 10.5 volts over a 20 hour period while the total actual amp-hours it supplies is measured. Sometimes ratings at the 6 hour rate and 100 hour rate are also given for comparison and for different applications. The 6-hour rate is often used for industrial batteries, as that is a typical daily duty cycle. Sometimes the 100 hour rate is given just to make the battery look better than it really is, but it is also useful for figuring battery capacity for long-term backup amp-hour requirements.

MilliAmp Hour means how much current a battery will discharge over a period of one hour. Higher numbers here reflect a long battery runtime and or higher storage capacity. Higher MAH ratings do not necessarily reflect on speed but more on runtime. For example a 2000 mAh pack will sustain a 2000 milli amp (2 amp) draw for one hour before dropping to a voltage level that is considered discharged. A 1700 will sustain a 1700 mAh (1.7 amp) draw for one hour. 1000 mAH is equal to a 1 Amp Hour (AH) rating.

A Volt is the unit of measure for electrical potential.

A WATT is the unit for measuring electrical power, i.e., the rate of doing work, in moving electrons by, or against, an electrical potential. Formula: Watts = Amperes x Volts.

A WATT-HOUR is the unit of measure for electrical energy expressed as Watts x Hours.

OHM is a unit for measuring electrical resistance or impedance within an electrical circuit.

OHM’S Law expresses the relationship between volts (V) and amperes (A) in an electrical circuit with resistance (R). It can be expressed as follows: V= IR Volts (V) = Amperes (I) x Ohms (R). If any two of the three values are known, the third value can be calculated using the above equation.

In a lead-acid battery, the electrolyte is sulfuric acid diluted with water. It is a conductor that supplies water and sulfate for the electrochemical reaction:

Liquid levels should be 1/8 inch below the bottom of the vent well (the plastic tube that extends into the battery). The electrolyte level should not drop below the top of the plates.

Under normal operating conditions, you never need to add acid or distilled water to a VRLA battery. For a standard auto or marine battery, only distilled water should be added to achieve the recommended levels which marked on the container. When a battery is shipped in a dry state or accidental spillage occurs, electrolyte should be added to the battery. Once filled, a battery should only need periodic water addition.
